1U Short Depth Chassis Ideal for Wall Rack/Appliance Servers - Clearance

1U Short Depth Chassis Ideal for Wall Rack/Appliance Servers - Clearance

PRODUCT CODE SKU: SC-1250
KEY PRODUCT FEATURES:
  • 1U Rackmount Form Factor
  • 250mm Chassis Depth
  • 430mm Chassis Width
  • 44.5mm Chassis Height
  • Flex ATX PSU Compatibility
  • Mini ITX M/B Form Factor
  • 1 Fixed Bays - Internal - 3.5"
  • 1 Fixed Bays - Internal - 2.5"
  • 1 Full Height PCI Expansion Slots
servercase-logo

Server Case are the European authorised distributor and retailer for Logic Case. Server Case have thousands of chassis and components in stock for easy purchasing and shipping to any worldwide location.

01283 576162 | [email protected]

www.servercase.co.uk

BUY SC-1250 NOW shopping-icon
  • Reliable and fast service Reliable and fast service
  • Global distribution Global distribution
  • High quality & affordable High quality & affordable
  • Stock held in UK Stock held in UK
logo-icon
Technical Details
Case Form Factor 1U Rackmount
Motherboard Compatibility Mini-ITX (6.7" x 6.7")
Drive Bays

External 5.25"

0
External 3.5" 0
Internal 3.5" 1 (Or 2 X 2.5")
Internal 2.5" 1 (Or 1 X 3.5")
Hotswap 3.5" 0
Hotswap 2.5" 0
Slim Optical 0
Slim FDD 0
Hot-Swap Backplane Not Applicable
Expansion Slots Full Height 1
Low Profile 0
Cooling 2 x 40mm fans complete with molex pass through connectors to run from PSU.
Power Supply Form Factor Supports 1U Flex or 1U Standard PSU (maximum length 200mm)
Front Panel Connectors, Switches & Indicators Power Switch YES
Reset Switch YES
USB 2.0 2
USB 3.0 0
Serial 0
Indicators Power and HDD LEDs
Colour Black
Material Steel
Dimensions & Weights
Packaging Single Box
Dimensions ( W x D x H ): 19" x 9.8" x 1.7" (430mm x 250mm x 44mm)
Weight 3.40 kg (Approx)
What's Included
  • 1 x Chassis
  • 1 x Accessory Box
