Logic Case LC-4480-WH 4U Rackmount Chassis - 15x Internal 3.5 Bays - 480mm Depth
Logic Case LC-4480-WH 4U Rackmount Chassis - 15x Internal 3.5 Bays - 480mm Depth
| PRODUCT CODE | SKU: LC-4480-WH |
|---|---|
| KEY PRODUCT FEATURES: |
|
Server Case are the European authorised distributor and retailer for Logic Case. Server Case have thousands of chassis and components in stock for easy purchasing and shipping to any worldwide location.
-
Reliable and fast service -
Global distribution -
High quality & affordable -
Stock held in UK
| Technical Details | ||
|---|---|---|
| Case Form Factor | 4U Rackmount | |
| Motherboard Compatibility | Mini-ITX, Micro ATX, Standard ATX (Max 12" X 9.6") | |
| Drive Bays |
External 5.25" |
3 |
| External 3.5" | 0 | |
| Internal 3.5" | 15 | |
| Internal 2.5" | 0 | |
| Hotswap 3.5" | 0 | |
| Hotswap 2.5" | 0 | |
| Slim Optical | 0 | |
| Slim FDD | 0 | |
| Hot-Swap Backplane | Not Applicable | |
| Expansion Slots | Full Height | 7 |
| Low Profile | 0 | |
| Cooling | 2x 80mm 4x 80mm |
|
| Power Supply Form Factor | Standard ATX or Mini Redundant | |
| Front Panel Connectors, Switches & Indicators | Power Switch | YES |
| Reset Switch | YES | |
| USB 2.0 | 2 | |
| USB 3.0 | 1 | |
| Serial | 0 | |
| Indicators | Power and HDD LEDs | |
| Colour | Black | |
| Material | SGCC | |
| Dimensions & Weights | ||
| Packaging | Single Box | |
| Dimensions | 446mm*430mm*178mm (D*W*H) | |
| Weight | 10kg (Approx) | |
| What's Included | ||
|
||
| Replaces Model | SC-H4-480 | |
